Casio UP-370 User Manual

– 12 –
THE DIP SwITCHES5.
DIP SwITCH 1 SETTING5-1.
= Default setting
No. Contents Status Status
1 Reset By Dtr Signals Off Invalid On Valid
2 Reserved Off Fixed to Off
3 Protocol Off XON/XOFF On DTR/DSR
4
Baud Rate
Refer to the table "Baud rate" below.
5
6
Parity Refer to the table "Parity" below.
7
8 Busy status Off Buffer full On Buffer full + OFFLINE
9
Low power
consumption mode *
Off Off On On
10 3 mm feed after auto cut Off Valid On Invalid
Printing speed is fixed to 150 mm/sec. (max.) and power consumption to approx. 8 A (max.) *
(instantaneous value).
Table "Baud rate"
No. 4800 bps 9600 bps 19200 bps 38400 bps
4 off off on on
5 off on off on
Table "Parity"
No. NON EVEN ODD NON
6 off off on on
7 off on off on
DIP SwITCH 2 SETTING5-2.
= Default setting
No. Contents Status Status
1 Data reception error Off Print "?" On Ignore
2 Bit length Off 8 bit On 7 bit
3 Reception buffer full Off *1 On *2
4 Undened Off / On /
5 Undened Off / On /
6 Undened Off / On /
7 Undened Off / On /
8 Undened Off / On /
*1: Until the room of the reception buffer increases from 1 Kbyte to 2 Kbytes.
*2: Until the non-processing data in the reception buffer decreases from 31 bytes to 21 bytes.
