– 2 –
PAPER SPECIFICATION1-2.
Paper Width 79.5 ±0.5 mm (3.13 ±0.02")
Paper Roll Size Roll diameter: Maximum 80 mm (3.15")
Take-up paper roll width: 80 +0.5/-1.0 mm (3.15 +0.02/-0.04")
Specied Paper Specied thermal roll paper: NTP080-80
[Paper: TF50KS-E2D Nippon Paper Industries Co., Ltd.]
Packaged roll paper:
[Paper: PD160R-N (Oji Paper Mfg. Co., Ltd.)]
The following paper can be used instead of the paper above:
Paper: HP220AB1 (Mitsubishi Paper Mills Ltd.)
Paper Roll Spool Diameter Inside 12 mm (0.47")
Outside 18 mm (0.71")
The end of the paper roll must be free to come off the spool when nished. It must not be NOTE:
adhesively attached or attached in another semi-permanent manner.
INTERFACE SPECIFICATION1-3.
RS-232C SPECIFICATION1-3-1.
Data Transmission Serial. EIA RS-232C compliant
Synchronization Asynchronous
Handshaking DTR/DSR or XON/XOFF control *
Signal Levels MARK = -3 to -15 V: Logic "1"/OFF
SPACE = +3 to +15 V: Logic "0"/ON
Baud Rate 4800, 9600, 19200, 38400 bps *
Data Word Length 8 bits, 7 bits *
Parity Settings None, even, odd *
Stop Bits 1 or more
Connector (Printer Side) Male DSUB-9 pin connector
The data word length, baud rate, and parity depend on the DIP switch settings. *
(Refer to "5. THE DIP SWITCHES".)
RS-232C INTERFACE CONNECTION EXAMPLE1-3-2.
HOST SIDE
(DTE ex.8251)
TxD
RxD
DTR
DSR
RTS
CTS
GND
PRINTER SIDE
(Pin No.)
RxD (2)
TxD (3)
DSR (6)
DTR (4)
GND (5)
To Next Page
