Selecting and Creating Tones
E-36
When the
bn
HOLD button is lit (by pressing it), the currently
sounding note or arpeggio (page E-40) will be sustained.
• Pressing
bn
HOLD again will cause its light to go out,
indicating that hold is turned off.
You can use the
bs
TRANSPOSE and OCTAVE (–, +)
buttons to change the pitch of the keyboard notes in
semitone or octave steps.
• For information about fine tuning the pitch in hertz steps
(Tuning), see page E-81.
1.
To change the pitch in semitone steps, hold
down
bs
TRANSPOSE as you press the
bs
OCTAVE minus (–) or plus (+) button.
• The setting range for this operation is one octave
upwards and downwards (–12 semitones to +12
semitones).
2.
To change the pitch in octave steps, use the
bs
OCTAVE minus (–) and plus (+) buttons
(without holding down
bs
TRANSPOSE).
• The setting range for this operation is three octaves
upwards and downwards (–3 octaves to +3 octaves).
• While the setting screen shown above is displayed you can
the
bp
dial or the
br
minus (–) or plus (+) buttons to
change the setting. If you do not perform any operation for
a while, the setting screen will be exited automatically.
You can apply reverb, vibrato, and other effects to notes to
enhance their sound.
■ Effect Block Diagram
Using the Hold Button
bn
Changing the Pitch of Notes in Semitone
Steps (Transpose) or Octave Steps (Octave
Shift)
bs
Lights when HOLD is on.
bs
Applying Effects to Notes
Sound
Source
(5) Master
Equalizer
Goes through (2), (3),
or (4). Also refer to
the “Chorus and DSP
Use Restrictions”
below.
Output
(1) Reverb
(2) Chorus
(3) Normal DSP
(4) Solo
Synthesizer
DSP
To Next Page
