E-8
Getting Ready to Play
• Whenever you connect any device to the Synthesizer, be sure to read the user documentation that comes with the device.
• This Synthesizer does not have built-in speakers. It will not produce sound unless you connect some device for sound output.
ck
Back left
cl
Back right
Connections
Memory card (page E-86) Computer (page E-92) Other electronic music instrument (page E-82)
(1) (2) (3) (5) (6) (7)(4)
*1 Standard plug (monaural)
*2 Stereo standard plug
*3 Stereo mini plug
Pedal Microphone Headphones Household
power outlet
CD player, audio player,
etc.
Audio device, amplifier, etc.
Other electronic music
instrument
*1 *3 *1 *1 *1 *2
Configuration
and type
depends on your
geographic
location.
