INTRODUCTION
Dear Purchaser, please read this note carefully, in addition to the straightforward
operating instructions for the machine, because the manuel also includes valuable
advice for optimising your manufacturing. Look at this symbol:
I - INTRODUCTION
We congratulate you on your wise decision and thank you for your trust.
The CS 910 is an underpinner which has been developed through extensive experience gained in
the manufacture of the reputable Cassese machines. It enables perfect joining of rectangular frames
and also various other forms including hexagons, octagons
Frames are joined by means of metal wedges which are specially designed for perfect locking.
The CS 910 requires minimum maintenance. Please, read the suggestions in section 5 carefully to
ensure years of professional use.
IMPORTANT :
USE CASSESE WEDGE MAGAZINES AND NO OTHERS (Trademark : CS)
II - ACCESSORIES BOX (supplied with the machine)
- 4 feet (for Junior model)
- 1 set or spacer bars for small mouldings,
- 1 adjustable triangle top plunger for soft wood,
- 1 Allen key N'.3(for top plunger - P) + 1 Allen key N' 2,5 (for block H)
- 1 spare hammer.
- 1 tube of grease
III- SPECIFICATIONS
• Net weight: 91 0 JR : 40 kg (85 lbs) ; 91 0 SR : 46 kg (100 lbs)
• Power supply: compressed air.
One power supply only, one setting only (6 - 7 bars) both for clamping pressure and for stapling
pressure
• Dimensions of frames : mini : 80 x 80 mm (3
l/7
"x3
1/7
") (bottom of rabbet)
• Width of moulding : mini : 5 mm (1/5") ; maxi : 85 mm (3
2/5
")+
rabbet
• Height of moulding : maxi 90 mm (3 1/2")
• Wedge sizes : 5 mm (3/16"), 7 mm (1/4"), 10 mm (3/8"),
12 mm (1/2"), 15 mm (5/8")
• Octogonal/hexagonal frame : A special shim is to be located in front of the stops
at 90°to produce the correct angle
IV • OPTIONS
• Table extension.
- 1 angled shim of 135°, 120°, etc...
For particular requirements, call in your sales contact.
V - WARRANTY
The CS 910 is guaranteed for parts and labour for one year, against manufacturing defects. Parts
worn through normal use and those damaged by operation contrary to the conditions of this manual
are excluded from this warranty.
910JRSR/02.94
- 1 -
