SET UP
I - INSPECTION OF CONTENTS
Please, inspect the contents of your box carefully. If you should note any crate damage,
please notify the carrier immediately to file a claim.
The following list of items should be found in your box
LIST OF ITEMS :
- 4 feet (for Junior model)
- 1 set of spacer bars for small mouldings,
- 1 adjustable triangle top plunger for normal wood,
- 1 N'.3 Allen key (for top plunger - P) + 1 N' 2,5 Allen key (for block H)
- 1 spare hammer.
- 1 tube of grease
II - ASSEMBLY
1 - For CS 910 Junior model : assemble the 4 feet of the machine (packaged with the
accessories).
On the CS 910 Sr (standing) model, the work bench of the machine is adjustable in height
(between 800 mm/31"
2
". - to 1000 mm/39 1/2") to fit any work table you may have in
your workshop.
NOTE : Please refer to the operating position as illustrated in Figure 1 for
all explanations for start-up and settings.
IMPORTANT ;
IN ORDER TO OBTAIN OPTIMUM OPERATION FROM
THE CS 910, WE RECOMMEND THAT YOU PERFORM
THE SETTING AND SERVICING OPERATIONS OF THE MACHINE
IN THE SEQUENCE SET OUT IN THESE INSTRUCTIONS.
Ill - CONNECTION OF MACHINE
Connect the CS 910 to a source of compressed, dry, filtered air, and check that the pressure
gauge reading is at least 6 bars (max 8 bars).
910JRSR/02.94
-3-
