Use Case C
Catchbox with an Audio System and a Computer
1. Plug the included USB data cable to to the computer's USB port and connect it to the Receiver's
micro-USB socket.
2. Plug the included audio cable to the Receiver's balanced audio output and connect it to the input
of your Audio System.
3. Turn on both the Transmitter and the Receiver.
4. Go to your computer's audio settings and enable the input signal from Catchbox. See detailed
instructions on Page 26.
Depending on the input type of your Audio device, you may need to use
additional audio adapters (purchased separately). Please refer to the wiring
diagram of the Receiver’s balanced audio output on (page 19).
POWER
AUDIO
