EFFE4 B - EFFE6 B
- 28 -
EFFE4-6 B_EN - 2010/07 Ed. 05
Fig. 26
11. Rotate the head to the left or right of the machine.
12. Remove the cover ring/chamber; it could be difficult. Using a
cloth, lift it by the front first and then the rear and slide out the
hair saver.
Fig. 27
13 Lift up and remove the whipping chamber.
Fig. 28
Fig. 25
10. Manual rotate the whipping chamber until the cou-
pling joint is positioned transversally to the machi-
ne.
