EFFE4 B - EFFE6 B
EFFE4-6 B_EN - 2010/07 Ed. 05
- 9 -
1. RECEIPT, MOVEMENT, UNPACKING
1.1 RECEIPT
• Before unpacking the machine, check that packing shows no external damages due to colli-
sions during transportation.
• An external damage could mean the machine itself is damaged: in this case, immediately apply
to insurance company and leave everything as it was on reception.
1.1.1 Lifting a packed machine
To lift the packing, insert lift forks into the space between pallet feet, so as to balance the machine
weight and consequently packing barycenter.
1.2 UNPACKING
Wooden packing can be opened with proper tools.
1. Remove the nails starting from the upper side until the machine still
secured to the pallet (board) ist left uncovered.
2. Remove protection sheet wrapping the machine.
3. Check that the machine has not been damaged during transporta-
tion.
Board packing is closed by steel straps on outside.
1. Cut the straps with snips, while keeping one end with your hands.
2. Withdraw the packing upwards.
3. Remove poystyrene and polypropylene bag protecting the ma-
chine.
4. Cut the straps securing the machine.
CAUTION
Protect your hands with gloves as one may hurt with splinters or
when cutting the straps if these are not strongly held.
Fig. 2
Fig. 3
1.1.2 Forbidden material handling equipment
Material handling equipment not in compliance with following safety characteristics must never
be used:
• Lifting capacity lower than machine weight
• Unsuitable construction features of the lift (ex.: too short forks)
• Construction features altered by use
• Unconforming ropes and cables
• Worn ropes or cables.
Fig. 1
NO!NO!NO!
