- Series S1500 & S3000 Connections -
S1500 & S3000
Autofill With
Bypass Option
S1500 & S3000
Standard Autofill
Lid Temperature
Probe Connector
Lid Monitor
Switch Connector
Lid Temperature
Probe Connector
Lid Monitor
Switch Connector
Fill Solenoid
Connector
Sensor
Hose
Fill Solenoid
Connector
Vent Solenoid
Connector
Vent Probe
Connector
Sensor
Hose
