Sensor
Hose
S5000 Manifold
Standard Autofill
Fill Solenoid Wire
To Control Unit
S5000 Manifold
Autofill With Bypass Option
Fill Solenoid Wire
Vent Solenoid Wire
Sensor
Hose
To Control Unit
Vent Probe Wire
- Series S5000 Connections -
