This section shows each display window and gives important information necessary for
understanding and operating the LCD text functions of the 2300 Controller.
To start, the index below shows where in this section to find each and every function of the
controller. This will enable the user to correctly program all functions of the storage unit to
meet their individual needs.
The overall operation consists of two basic modes: the Standard Operating Mode, and the
Program Mode. The unit is in the Standard Operating Mode when the Program/Lock Keyswitch
on the front panel (page 6, number 9) is turned to LOCK. To enter the Program Mode the key
must be inserted and the switch turned to PROGRAM.
In the Standard Operating Mode there are 6 different displays possible. They are as follows:
Standard Display - Display number 1 - page 16
Standard Display while unit is filling - Display number 2 - page 16
Standard Display with lid open - Display number 3 - page 17
Alarm Condition Display - Display number 90 - page 17
Alarm Condition Display with audible alarm muted - Display number 91 - page 17
Printing Report - Display number 99 - page 17
The Alarm Condition Display will give the specific cause of each alarm condition that
may be occurring. The following is a list of the possible alarm conditions:
Low Alarm Fill Valve
High Alarm Bypass Valve
Source Alarm Open Lid Probe
Temperature Alarm Open Vent Probe
In the Program Mode there are various displays possible. The following is a list of programming
functions and the corresponding display windows. For each of these programming functions
there may be sub-menus that follow the primary display window. The sub-menus are not listed
here but are shown and explained following the primary windows. The primary programming
functions are as follows:
Main Menu - Display number 4 - page 18
Provides access to:
Date/Time Settings - Display number 8 - page 19
Tank ID Settings - Display number 13 - page 19
Liquid Level Settings - Display number 15 - page 20
Main Menu 2 - Display number 5 - page 18
Provides access to:
Lid Temp Settings - Display number 19 - page 20
Report Functions - Display number 22 - page 21
Bypass Settings - Display number 24 - page 21
Main Menu 3 - Display number 6 - page 18
Provides access to:
Control Validation - Display number 40 - page 21
Fill Timer Settings - Display number 7A - page 18
Return to Main Menu - Display number 4 - page 18
