CBS V3000 - Page 41

38
- Troubleshooting Guide: Alarms -
■ **BYPASS VALVE** text is
flashing and audible
alarm is present
(screen #90 on page 17)
■ **OPEN LID PROBE** text
is flashing and audible
alarm is present
(screen #90 on page 17)
■ **OPEN VENT PROBE** text
is flashing and audible
alarm is present
(screen #90 on page 17)
■ Any **ALARM** text is
flashing and an audible
alarm is NOT present
(screen #91 on page 17)
• Bypass Valve disconnected
from power source
• Bypass Valve defective
• Thermocouple Probe plug is
disconnected
• Thermocouple Probe is
damaged
• Thermocouple Probe plug is
disconnected
• Thermocouple Probe is
damaged
• There is an alarm condition
of some kind and the alarm
MUTE is activated
• Connect Bypass Valve power
cord correctly using diagram
on page 7
• Replace Bypass Valve
• Connect Probe plug properly
using diagram on page 7
• Replace damaged probe
• Connect Probe plug properly
using diagram on page 7
• Replace damaged probe
• Correct the alarm condition
and then push the SOUND
switch, so the audible alarm
will be activated at the next
alarm occurrence
CONDITIONS
CAUSES
SOLUTIONS
LIQUID LEVEL XX.XCM LID TEMP.-XXX C
SYSTEM STATUS BYPASS VALVE
FILL/START FILL/STOP MUTE REPORT
o
BYPASS VALVE
** **
** **
LIQUID LEVEL XX.XCM LID TEMP.-XXX C
SYSTEM STATUS OPEN LID PROBE
FILL/START FILL/STOP MUTE REPORT
o
OPEN LID PROBE
** **
** **
LIQUID LEVEL XX.XCM LID TEMP.-XXX C
SYSTEM STATUS OPEN VENT PROBE
FILL/START FILL/STOP MUTE REPORT
o
OPEN VENT PROBE
** **
** **
LIQUID LEVEL XX.XCM LID TEMP.-XXX C
SYSTEM STATUS ANY ALARM
FILL/START FILL/STOP SOUND REPORT
o
SOUND
** **
www.custombiogenics.com
