16
Legend for the illustration above (all dimensions in [mm]) Wiring

P1
P2

Isolated wire 0.5qmm, PVC red, diameter max. 2.2mm
1

Isolated wire 0.5qmm, PVC black, diameter max. 2.2mm
2

Male connector with CAGE-CLAMP, WAGO 733-204
3
4

Shrink tube, black
4
3

Cable retainer 2.5 mm width
5
black – GNK
2

Strain-relief, WAGO 734-127
6
red - Power
1

Female connector with CAGE-CLAMP, WAGO 733-106
NO
DESCRIPTION
For a safe environment you have to use the terminal with a central power supply of your machine. You can
order a cable for that operation with part number 03492-91.
Adapter cable two wires to 6pin, 2000mm
