CCV IM30 - Datasheet Summary

Manual - CCV IM30
31
11 Datasheet
Product
CCV IM30
Part Number:
03385-55
03397-55
Configuration Options
LAN
X
X
Bluetooth
X
X
WiFi
X
X
RF Modem
X
-
Power supply
Supply Voltage
7 - 48 VDC via main power connector
7V - 48V DC via MDB Standard
7V - 48V DC via RS232
19V - 30V AC via Executive and optional MEI cable
Power
Consumption**
Full Operation:
< 650 mA peak without active 4G modem
Power Save Mode:
typ. 6mA in without active 4G modem
Max. power 700mA@12V
Full Operation:
< 500 mA peak
Power Save Mode:
typ. 5mA
Wake-Up
Hands-free via integrated Proximity sensor, <8cm
Magnetic stripe card swipe | Contact Card insertion
Wake-up line via MDB, RS232 and the 20pin Telemetry connector
Processing Power
µController
Quad-core Cortex-A53, 1.2GHz
OS
PayDroid Powered by Android 7.1
Memory
2GB LPDDR3, 8GB Flash
Interfaces
RS232
2x RS232, RJ45
USB
USB Host, USB Type A | USB OTG, USB Type C
LAN
LAN, 100MBit, RJ45
WLAN
2.4/5GHz WiFi integrated
2.4/5GHz WiFi integrated
