ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
EN
ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
Cabinet Side View
Cabinet Door
Nut
Spacer
Spacer
Screw
Spacer
Installthewalltamperswitchusingthesuppliedboltsandnutsasshowninthefollowingpicture.
Installthetamperswitch
plasticspacerontheback
atbottomleftsideof
the box as show in
the following picture.
