Location and Mounting
Thecabinetisdesignedtobeinstalledindoors,inasafeandsecurelocation.Normaltemperatureandhumidity
levelsshouldbemaintained.
CabinetDimensions:
 40cm(15.8”)high,32cm(12.6”)wide,9cm(3.54”)deep
TheCabinetCanAccommodate:
 One12Vdc@4.5AHor7AH,gelcelltypebatteryandwiringconnections(15cm(6”)high,
 6cm(2.5”)wide,9cm(3.54”)deep)
Battery Model Voltage Capacity Length Width Height
YUASA#NP7-12 12Volt 7 Ah 151mm(5.94”) 65mm(2.56”) 97.5mm(3.84”)
YUASA#NP4-12 12Volt 4.5Ah 90mm(3.54”) 70mm(2.76”) 106mm(4.17”)
MultipleConduitKnock-outs:
 Two19.05mm(0.75”)oneachsideandone12.7mm(0.5”)ontop
MinimumClearanceForCabinet:
 25cm(10”)clearspacearoundallsides
 38cm(15”)clearspaceinfrontofcabinet
MinimumClearanceFromElectricalInterference:
 2.4m(8ft.)fromhighvoltageequipmentorwiringandfromelectricalequipmentlikelyto
generate interference
 1.2m(4ft.)fromtelephoneequipmentorlinesand8m(25ft.)fromtransmittingequipment
Thesystem’slocationandwiringmethodsshallbeinaccordancewiththeNationalElectricalCode,
ANSI/NFPA70.
