4] MOUNTING INSTRUCTIONS
Theboxneedstobepreparedbeforexingittoitslocation.
INSTALLING THE TAMPER SWITCHES
InstallingtamperswitchesallowstheADH10todetectwhenthecabinetdoorisopenedand/orwhenthe
cabinetisremovedfromthewall.Ifneededinstallthetamperswitch(es)asfollows:
Metal box
holes where
toxthewall
tamperswitch
