CDVI ATRIUM ADH10 - Package Contents

7
cdvigroup.com
EN
ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
EN
ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
3] PACKAGE CONTENTS
This chapter details how to install and setup the 10-Door Handle Controller.
What’s in the box:
 •OneADH10controller
 •metalcabinetandconnectiondiagramlabel
 •ACpowercord
 •Metalcabinetaccessorykit
 •Installationkit
Wall Switch
and a white
wire (115mm)
with a log at
each end
Bolts and Nuts
Wall Switch
Spacer
Door Switch
and 2 white
wires (350mm)
with a log at
one end
Door Switch
Support
Metal box
screw
Metal box
lock and key
Metal Cabinet
Accessory Kit
1 2 each 1 1 1 4 1
Pair of Wire,
Red and
black, for
backup battery
(400mm)
Fastener
(PCB Holder)
Installation
Kit
1 pair 5
