ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
EN
ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
1] PRODUCT PRESENTATION
One ATRIUM ADH10 controller has the capacity to control ten NDE, AD300 and/or AD400 SCHLAGE door handles.
ATRIUM ver. 3.1 (or higher) multi-account software supports up to 100 door handles per account (site). This
is accomplished by using ten ADH10 controllers connected to an IP network. Eortless auto detect technology
identies the SCHLAGE door handle on the communication bus. A pre-assembled universal power supply is
included with every ADH10 making this unit an industry leader in eciency and simplicity.
• Control10doorhandles
• On-boardEthernetPortwithAES256-bitencryption
• Auto-detecttechnology
• 10,000users
• 10,000cards
• 25,000EventBuer
• 100holidays
• 1,000AccessLevels
• 1,000Scheduleseachsupportingupto
 100timeperiods(dd,hh:mm)andrecurrence
• Fullcalendarwithleapyearsupport
• Timezonedenition(fullD.S.T.support)
• 1220m(4000ft)4conductorRS-485expansionbus
 (NojumpersorDIPswitches)
• ComprehensiveLEDstatusindicators
SCHLAGEDOORHANDLECOMPATIBILITY:
AD-300
Hardwired Electronic Lock
AD-400
Wireless Electronic Lock
(Work with PIM400-485)
NDE
Wireless Electronic Lock
(Work with GWE)
900MHz
Pre-assembled
universal power supply
included
Low Energy
