Fixing the Box to its Location
Install the box to its location using 4 screws (not supplied) as shown in the following picture.
Ifthewalltamperswitchisused,makesurethatthetamperswitcharmmovesfreelyandis
completelypushedinwhentheenclosureisinstalledonthewall.
