ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
EN
ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
RecommendedWiring
Specications
Equipment WireType Size
Maximum
Length
Ethernet CAT 5/5e - 100m (300ft)
RS485 bus
(Daisy Chain)
Belden 9841, 9842 or equivalent
(2 or 4 conductor shielded)
24AWG (0.51mm) 1220m (4000ft.)
* The Minimum Size Equipment Conductors for the AC mains required are 14 AWG if made of Copper or 12
AWG if made of Aluminium or Copper-Clad Aluminium. Do not use any switch-controlled outlets to power the
system.
SystemResources
Doors 10 doors
Cards and users 10,000 cards and users
Schedules 1000 Schedules each supporting up to 100 time periods
Buered Events 25,000 events
Holidays 100 holidays
Access Levels 1000 access levels
Operating Temperature -20°C to +70°C (-4°F to +158°F)
Humidity 0% to 85% (non-condensing)
System Autonomy Full Distributed Architecture (100% O-line Operation)
Firmware Online Upgradeable
PCB Dimensions 19.9cm (7.83”) x 12.38 cm (4.875”)
Cabinet Dimensions 29 cm (11.4”) high, 28 cm (11”) wide, 8 cm (3.15”) deep
Inputs
Box Tamper Normally Closed (N.C.) contact
