ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
EN
ADH10
ATRIUM - Schlage Integration Module (Control up to 10 Schlage Door Handles)
INSTALLATION MANUAL
Communication
LOCAL BUS RS485 @ 9600Baud supporting daisy chain topology, up to 4000ft (1220 meters)
ETHERNET 10/100 Base-T, Auto Sensing, 100m(300ft)
PowerSupply
AC Power 120-240Vac, 1.2A
Frequency 50Hz/60Hz
Output 24Vdc, 2.5A
AC Terminal Fuse 250Vac, 2.5 A, Time Lag, Slow Blow, Operating Temperature: -55
o
C to +125
o
C
Power Loss Indicator Yes (DC IN)
Do Not Connect to a Receptacle Controlled by a Switch.
On-BoardProtection(Fuseless,auto-resume)
Battery Against reversal, short, current limited/monitored
Poweroutputspecications
BatteryBackup
Battery Capacity
12Vdc 7Ah rechargeable acid/lead or gel cell backup battery (UL/ULC: YUASA #NP7-12
recommended, Europe: CDVI B7AH recommended). Ensure proper polarity.
Charging Current
250mA (default), 320mA, 500mA, or 1A. Refer to the user interface instruction manual for more
information on how to modify the battery charging current.
Low Battery @ 11.8Vdc
Low Battery Restore @ 12.2Vdc
Low Battery Cut-O @ 10.5Vdc
PowerOutputs(+12Vdc)
LOCAL BUS Maximum Current 1000mA
