ENGLISH
25
4. OPERATION
4.1 TOUCH DISPLAY
1. Power button
2. Wi-Fi indicator light
3. Battery indicator light
1. ON/OFF
• Press to start the robot up.
• From the standby mode:
- Press to start auto cleaning mode.
- Hold down from 3 to 5 seconds to enter network conguration.
- Hold down for 7 seconds to enter sleeping mode.
• During operation:
- Press to stop operation.
• During charging:
- Press to enter auto cleaning mode.
2. Wi-Fi indicator light
• When entering network conguration (see before section), the white light will blink
slowly.
• When the device connects to the Wi-Fi, the white light will turn steady.
• If the device fails to connect, the white light will blink faster.
3. Battery indicator light
• The light will turn red when the battery is low.
• The light will switch from blue to red alternately during charging.
• The light will turn steady blue when it is totally charged.
4.2 BATTERY CHARGING
1. Charging base
• Place the charging base against the wall.
• Remove any obstacle from around the charging
base, following the safety distances shown on the
below picture:
• Always turn the robot’s power switch ON before
placing it on the charging base.
2. Connection
• Plug one of the adapter ends into the robot’s charging socket and the other to the
power supply. (Fig. a)
1
3
2
