21
• CEDIMA® • Technical Documentation • All rights reserved according to ISO 16016 • Changes serving technical progress reserved •
Maintenance and care
Joint cutter CF•22 E
When carrying out maintenance and care work, follow the
“Basic safety instructions” in chapter 3 of this operating
manual!
• The joint cutter has to be cleaned before each mainte-
nance!
• Care and maintenance work has to be carried out
according to the cycles described in chapt. 5.5! Also
check and if necessary change or adjust all wear parts
that have not specically been included in the listed
maintenance intervals.
Keep exactly to the care and maintenance intervals! This
will lengthen the life of your machine!
DANGER!
Risk of injury!
The joint cutter CF-22 E has to be switched OFF
when care and maintenance work is being carried out!
Switch o the blade drive motor! Disconnect the joint
cutter from the mains!
Secure the joint cutter against unintentional starting and
rolling o!
5.1 Cleaning
Cleaning agents
– Do not use any aggressive cleaning agents
(solvents, acids or similar)
• High-pressure cleaners and aggressive cleaning uids, as
well as cleaning with uids of exceeding a temperature
of 30 °C are not allowed!
– Use lint-free cleaning cloths!
5.2 Cleaning procedure
Dry cleaning
– Remove dust and dirt with a lightly damp cloth!
– Remove stubborn crusty sediment with a (not too hard)
brush!
Wet cleaning
ATTENTION!
Do not use high-pressure cleaners respectively
steam cleaners!
For safety reasons, no water / cleaning liquid may pen-
etrate the electric motor, plugs and switch box with the
star-delta reversing switch!
– Therefore, cover or seal all openings, casings, plug con-
nectors etc. which are at risk!
– Remove dirt and residues with a “gentle” jet of water and
a (not too hard) brush.
– Be especially careful at the critical parts (e.g. electric mo-
tor, switches,…)!
The electric motor as well as all electrical components may
not be cleaned with a water jet!
– To avoid them running dry, do not rinse the bearings
with water! The bearings are lubricated for life.
– After cleaning, covers or sealing materials are to be
removed completely!
Re-greasing, corrosion protection
– After cleaning, provide the metallic sliding parts (spindle
g. 4.13) with a thin coating of grease (anti-rust protec-
tion) or corrosion protection oil! All other metal bearings
and movable machine parts should never run dry, but
slightly be greased with a thin lm of multi-purpose
grease and machine oil!
Excessive grease and oil promotes wear and tear
due to adhesive dust and dirt (slurry) clinging to the
machine!
– Check all connections and connecting elements be-
tween the components and re-tighten screw connec-
tions that may have become loose (see section 5.4)!
5.0 Maintenance and care
