Technical data and accessories
1.0 Technical data and accessories for the CEDIMA® joint cutter CF•22 E
1.1 Technical data
Drive motor
Max. motor output
Speed
Voltage
Amperage
Starting device
electric motor
7.5 kW
2900 min
-1
400 V / 50 Hz
16 Ampere
Star Y delta ∆ reversing switch
Type of protection IP 54
Blade mounting Ø 25.4 mm
Drive pin Ø 8,0 mm
Max. saw blad clamping width 6,0 mm
Cutting shaft rpm 1630 min
-1
Max. saw blade diameter 700 mm
Max. cutting depth 270 mm
Cutting depth adjustment manually over a lockable hand crank (threaded spindle)
Saw blade receptacle side right or left
Feed manuell
Water supply Pressurised water with GEKA connection
Dimensions
Length / width / height 1350 mm / 660 mm / 930 mm
Weight
dismountable in:
Rocker with motor and cutting shaft
Frame
Blade guard
110 kg
60 kg
30 kg
20 kg
Sound pressure level at the workplace *
Measured acoustic power level *
L
PA
= 78 dB (A)
L
WA
= 94 dB (A)
* Higher values are possible during cutting.
