Maintenance and care
Joint cutter CF•22 E
5.8 Transporting the joint cutter CF•22 E
DANGER!
Risk of injury! The joint cutter must always be
switched o before transport, secured against
unexpected restarting and against rolling away!
Disconnect the mains power connection, pull out
the mains plug!
• Uncouple the external compressed water hose and drain
the cooling and ushing system completely!
• Dismount the diamond saw blade!
Do not transport the joint cutter with the diamond saw
blade mounted!
• Transport the joint cutter upright and horizontally!
• Swivel up the front pointer!
• Lower the cutting shaft up to the stop!
• Push completely in the push handle and secure.
ATTENTION!
The push handle is not designed for transport by crane!
• Pay attention on the rm seat of all joint cutter compo-
nents (tools,...).
• Use the two push handle pipes and the rocker for lash-
ing!
• Dismantle the joint cutter in the appropriate (3) parts
(see sect. 4.1.1).
Check all connection, attachment elements and modules
after transport for rm and correct seat!
5.9 Longer periods out of service/storage
• Note the above-mentioned points for transport
• Observe maintenance intervals and carry out mainte-
nance work!
• Release the tension of V-belts!
• Turn the cutting shaft (motor) roughly once a month (by
hand) through some revolutions!
• Actuate functions roughly once a month!
• Relieve the wheels (protect the base of the tire) by sup-
porting the joint cutter frame with suitable pieces of
wood!
• Store the joint cutter in a dry, frost-free and dust-proof
place and also protected against extreme sunlight, tem-
peratures (uctuations) as well as vibrations and other
negative physical and chemical eects!
• Check that all of the screws and assemblies are correctly
seated (rmly)!
