17
EN
OPERATOR’S MANUAL
VENUS PLUS MCT version model lights:
• Continuous operation.
• Power supply voltage: 18 V~ 50/60 Hz (code 96601069), 24 Vdc (code 96601070).
• Power absorbed: 15 VA (code 96601069), 15 W (code 96601070).
• Light spot dimensions: 225 mm x 95 mm (with illuminance at 1200 lux).
• Standard mode max illuminance (lux): 50,000 (+/- 10%).
• Curing safe mode max illuminance (lux): 15,000 (+/- 10%).
• Colour temperature in standard mode: 4300 K, 5000 K, 5500 K (+/- 5%).
• Colour temperature in curing safe mode: 2700 K (+/- 5%).
• Light source: 6 power LEDs.
• Maximum temperature on accessible surfaces (during normal use): < 50°C.
• Totalweight:5.5kg.
VENUS PLUS CL MCT version model lights:
• Continuous operation.
• Power supply voltage: 100/115/230 V~ 50/60Hz.
• Power absorbed: 18 VA.
• Light spot dimensions: 225 mm x 95 mm (with illuminance at 1200 lux).
• Standard mode max illuminance (lux): 50,000 (+/- 10%).
• Curing safe mode max illuminance (lux): 15,000 (+/- 10%).
• Colour temperature in standard mode: 4300 K, 5000 K, 5500 K (+/- 5%).
• Colour temperature in curing safe mode: 2700 K (+/- 5%).
• Light source: 6 power LEDs.
• Maximum temperature on accessible surfaces (during normal use): < 50°C.
• Totalweight:22.5kg.
• Fuse F1 (Transformer Primary Cir.): T4A.
• Fuse F2 (Transformer Secondary Cir.): T6.3A.
• Installation diagram: 97042189.
VENUS E version model lights:
• Continuous operation.
• Power supply voltage: 12-24 V~ 50/60 Hz.
• Power absorbed: 20 VA.
• Light spot dimensions: 80 mm X 160 mm.
• Lighting (lx): 40,000 (max).
• Colour temperature: 5000-6000 °K.
• Light source: 6 power LEDs.
• Maximum temperature on accessible surfaces (during normal use): < 50°C.
• Totalweight:5.7kg.
