CEFLA VENUS PLUS - Applied Parts; Equipment Description

7
e
d
a
b
c
c
e
b
f
d
a
e
d
a
c
k
c
a
d
k
EN
OPERATOR’S MANUAL
1.5. APPLIED PARTS
The parts of the equipment which may come into
contact with the patient during operation are the front
panels of the light.
2. EQUIPMENT DESCRIPTION
Equipment description.
VENUS PLUS, VENUS PLUS CL version light
body:
a) Optical unit.
b) Transparent screen.
c) Removable handles suitable for cold sterilization.
d) ON switch.
e) Brightnessadjustmentknob.
VENUS PLUS -L version, VENUS PLUS CL -L
version light body:
a) Light source consisting of 2 multichip LEDs.
c) Removable handles sterilizable inside autoclave.
d) ON switch.
e) Brightnessadjustmentknob.
k) NOTOUCHsensorforturningonandbrightness
adjustment.
VENUS PLUS MCT version, VENUS PLUS CL
MCT version light body:
a) Light source consisting of 6 LEDs.
b) Removable handles sterilizable inside
autoclave.
c) Brightnessadjustmentknob.
d) NO TOUCH sensor for turning on and
brightness adjustment.
e) Buttons for selecting standard/curing safe
mode and colour temperature in standard
mode.
f) Colour bar to display the selected colour
temperature.
VENUS PLUS E version light body:
a) Light source consisting of 6 LEDs.
c) Removable handles suitable for cold sterilization.
d) ON switch.
k) NO TOUCH sensor for turning on and
brightness adjustment.
