- 20 -
Drop the assembly into the
Xpress
insert slot.
Screw the bolt into one of the threaded inserts; the end of
the bolt needs to just protrude from the bottom of the
insert.
Repeat for all positions on both
Xpress
ports. (two positions on front
mounted, four positions on side mounted). Allow the assembly to drop
into the top slot.
Bring the two Ports together.
Lift the bolts and inserts clear of the Port.
Note: you may have to rotate the bolt up to 90 degrees in order
to make the bottom insert line up with the hole in the bottom of
the port, only rotate clockwise to avoid unscrewing the insert.
