Operation Instructions Icons
27
5.6 Icons
1) 273B 278BBattery Capacity - Fully charged battery.
2) 274B 278BSD Card - Indicates an SD card has been inserted into the tool.
3) 275B 278BStill Camera - Indicates the tool is operating in still camera
mode.
4) 278B Video Camera - Indicates the tool is operating in video camera
mode.
5) 278B Record sound - Push OK to record sound in the photo play
mode.
6) Record - Press OK to record in the photo record mode.
7) Stop - Press OK to stop playing recording in the photo record
mode.
8) 278B Play - Press OK to play recording in the photo record mode.
9) 278B Pause - Press OK to pause playing recording in the photo record
mode.
10) 278B Delete - Press OK to delete the recording in the photo record
mode. (You will be prompted: “Are you sure you want to delete this
file,” before deletion is completed.)
