FORGE OUTDOOR COAL FURNACE • OWNER'S MANUAL
Menu # Setting Bituminous Anthracite MIN MAX
13 RESET CYCLE OVER AIR START SETTING
Over air opening starting height as a percentage of full travel
when the RESET button is pressed. The actuator will decrease
from this setting to the end setting.
75 0 0 100
14 RESET CYCLE OVER AIR END SETTING
Over air actuator height as a percentage of full travel when
the RESET function has nished.
0 0 0 100
15 RESET CYCLE OVER AIR DURATION (MINUTES)
Sets the over air open duration when the furnace starts up
after being in Idle Mode. Helpful in reducing pu backs.
30 30 0 59
16 STOP CYCLE OVER AIR SETTING (PERCENTAGE) 50 50 0 100
17 PULSE CYCLE UNDER AIR SETTING
Under air actuator start height as a percentage of full travel
when the Pulse function is operating.
25 25 0 100
18 PULSE CYCLE OVER AIR SETTING
Over air actuator starting height as a percentage of full travel
when the Pulse function is operating.
0 0 0 100
19 PULSE CYCLE DELAY DURATION (MINUTES)
Time in minutes between pulses when furnace is in Idle
mode.
30 30 0 59
20 PULSE DURATION (MINUTES)
Time the fan is on and actuators are open during Pulse
function.
1 1 0 59
21 STOP CYCLE LENGTH (MINUTES)
After the water temperature setpoint is reached, the time the
over air continues to run to purge the rebox of smoke and
volatiles.
2 2 1 20
22 COMBUSTION TEMPERATURE SENSOR ERROR
(0=no error, 1=open circuit, 2=short to ground, 3=short to
5VDC).
0 0 0 3
23 FAHRENHEIT/CELSIUS
(0 for Fahrenheit, 1 for Celsius).
n/a n/a 0 1
24 WATER TEMPERATURE OFFSET
This variable is added to (or subtracted from) the Water
Temperature Display.
0 0 -30 30
25 COMBUSTION TEMPERATURE OFFSET
This variable is added to (or subtracted from) the Combustion
Temperature Display.
0 0 -30 30
26 WI-FI ENABLED
(0=disabled, 1=enabled).
0 0 0 1
27-40 Menu items 27-40 are variables used with the FireStar and
MyFireStar.com systems.
