FAAC 844
TECHNICAL DATA
844
8443 PHASE
Power supply
230V ~ (+6% - 10) 50Hz 380V, 3 Phase
Absorbed power
650W 950W
Current draw
3.5A 1.9A
Max. Starting pull 45kgf (Z16) - 35kgf (Z20) 45kgf (Z16)
Temperature range
-20° to 55°C -20° to 55°C
Motor speed
1400rpm 1400rpm
Reduction ratio
1 ÷ 30 1 ÷ 30
No. Of pinion teeth
Z16 (Z20) Z16
Rack pitch 4 Module 4 Module
Operating speed
9.5m/min (Z16), 12m/min (Z20) 9.5m/min
Winding thermal protection
120°C 100°C
Duty cycle
40% 60%
Oil quantity
1.8 Litres 1.8 Litres
Type of oil
FAAC XD 220 FAAC XD 220
Housing protection
IP55 IP55
Gear motor weight
14.5kg 16kg
Starting capacitor
35µF N/A
Clutch
Bidisk in oil bath Bidisk in oil bath
Control unit Centurion CP81 Centurion CP81 3 Phase
Limit switch Inductive Inductive
Max. Gate mass
(Z16) 1800kg (Z16) 2200kg
(Z20) 1000kg (Z20) 1000kg
Type of cooling
Oil Oil
Anti-crushing control
Slipping clutch in oil bath Slipping clutch in oil bath
