52
000000000000
9000000000
2. If one event code isn’t to be reported to CS, the 2 digits which correspond to the event will be set as [00] value.
Remarks:
1. Delay for sending to the central stations the “AC power loss” / “AC power Restore” event codes (or “AC power loss” to initiate voice/sound reporting) will be programmed in section [039].
2. Delay for sending to the central station the “Low Voltage on Battery”/”Restore Voltage on Battery” event codes is 2 min. and it isn’t programmable.
3. Event codes for “Bell Trouble”/”Bell Trouble Restore” and “AUX Overload”/”AUX overload Restore” are sent to the central station at the very moment when they occur.
Section [061]: Event Reporting Codes in 4x2 Format regarding: Programming Entry / Programming Exit / PC
connected / PC disconnected / LOG 90% full / LOG 100% full
Enter 6 groups of 2 digits (HEX digits may be used), one group for each reporting event.
The keypad buzzer will sound 3 beeps after each 2-digit group and 6 beeps after the last one. Then the panel exits the section and will wait for a
new command.
To exit the “main programming menu”, press [#] key.
Notes:
1. If one event code should keep its value previously set, press [#] key instead of the corresponding group.
2. If one event code isn’t to be reported to CS, the 2 digits which correspond to the event will be set as [00] value.
Section [062]: Event Reporting Codes in 4x2 Format regarding: Periodical Test / Panel Programming Changed /
Maintenance Request / PGM Activation by User / PGM Deactivation by User / Communication to CS
failed
Enter 2 groups of 2 digits, 3 groups of 1 digit and 1 group of 2 digits (HEX digits may be used), one group for each reporting event.
The keypad buzzer will sound 3 beeps after each group and 6 beeps after the last digit of the last group. Then the panel exits the section and will wait for a new command.
To exit the “main programming menu”, press [#] key.
Notes:
1. If one event code should keep its value previously set, press [#] key instead of the corresponding group.
2. If one event code isn’t to be reported to CS, the 2 digits (or 1 digit) which correspond to the event will be set as [00] value (or as [0] value).
3. By default, the periodical test code will be transmitted to CS after 24 hours since the first periodical test.
4. In case of any 4x2 formats (4 account digits + 2 event digits) were set by programming, in order to get the 2 event digits, then the panel will automatic add to the specific digit for “PGM
activation/deactivation by users”, which are set in this section, the corresponding digit of the user number. For all users from 15 to 45, the user number will be reported either as “F” or as
modulo 16, according to the corresponding flag programming from section [032]. In any 4x2 formats the “installer’s maintenance code” is identifying as user “0” and PC is identifying as
user “F”.
Section [063] to [073] – EVENT Reporting Codes in Contact ID Format:
Notes:
1. In case of transmission to CS was set (in section [049]) to be done in CID format (4 account digits + 4 event digits + 3 zone/user digits), after the 4-digit group specific to each
reporting event the panel will transmit to CS another 3-digit group which stands for user/zone number identifying. In CID format:
- Any action performed by the installer is identifying as user “000”,
- Any action occurred at a time is identifying as user “999” and
- Any action performed by PC is identifying as user “255”.
2. By programming you can change only the last 2 digits of any 4 event digit group.
3. If one CID code isn’t to be reported, enter 2 digits of [0] for last 2 digits of the 4 event digits.
4. If CID code is still to be reporting as [xx00], enter 2 digits of [A] for last 2 digits of the 4 event digits.
