Power and grounding specifications
Use DC24V as PV037 power input. The power consumptions are as following table. To
ensure the PV037/PV057 hardware working properly, to avoid outside
electromagnetism noise, please ground the power source properly.
Items
Models
PV037-LSK
24VDC
±
10%; 6W 24VDC
±
10%; 10W
Fuse Rating
0.5A 0.8A
Power grounding caution: The products are all equipped with power terminals and lock
assembling sets. The operating procedure is:
１．Screw off the power terminal.
２．Peel the 24V wiring(1.25mm) for 1 cm then plug in the power terminal.
３．Use line screw driver to screw the power terminal tight.
Package content
We are appreciated for your purchasing our products. Our standard package should be
equipped with 5 items as following. Please check after receiving it. If there’s any
shortage, please refer to the suppliers.
PV035/037/057/058/GD057/GD058; PL035/PL037/PL057 unit x 1 (HMI Hardware)
Power terminal x 1 (power terminal)
Communication terminal x 1 (4-pin communication connector)
Installation screw nuts x 4 (Lock for assemble with screws)
PV037/PV057/PV058/GD058 Installation Guide x 1 (Installation manual)
Cautions
If this product is used in a house, radio-wave interference might occur to other devices.
In the case that it does occur, the user is requested to try a variety of remedies to solve
the problem.
