Cermate Technologies PL035-TST - PV058 and GD058 Specifications

PanelVisa
A-6
PV058/GD058 Specifications
Items
PV058-TST PV058-TNT GD058-TST
Display Type
Color mode TFT LCD,
256 colors
Display Size 5.7" (diagonal)
Number of Pixels 320x240
Display Adjustment Brightness adjustable from touch screen
Back Light LED; Life time is 50,000 hours
Touch Screen
Analog resistive type; Max. Number of switches are 40x30
Chemically strengthened glass backing panel;
Over 1 million point activations;
Hard coat is resistant to most solvents and chemicals
Input Power
24VDC±10%; Isolation; Under 10W
CPU
RISC ARM 32Bit CPU
Flash Memory
4M Bytes
System working Memory
1M Bytes 2M Bytes 1M Bytes
Battery Backed Memory
128K(Standard)~1M Bytes
Communication Ports
COM1/9pin: RS232/RS422/RS485 .
COM2/9pin: RS232 .
COM2/Terminal 4Pin : RS422/RS485
COM1/9pin:
RS232/RS422/RS485
Com2/25pin:
RS232/RS422/RS485
ProfiBus Port
Optional with extension card
Front Panel Seal
IP65 / NEMA 4
Operating Temperature
0~50°C
Storage Temperature
-20~60°C
Ambient Humidity
20-90% RH (non-condensing)
Vibration Endurance
0.5mm displacement, 10-55Hz, 2hours per X, Y, and Z-axis
directions
Shock Endurance
10G, 11ms three times in each direction of X, Y, and Z axes
RFI testing
FCC Part15 Class A
Radiated Disturbance Test
EN 55022/1998+A1:2000
Electrostatic Discharge Test
EN61000-4-2/1995+A1:1998
RF Electromagnetic Field Test
EN61000-4-3/1996+A1:1998
Surge Immunity Test
EN61000-4-5/1995
EMC Test Report
EN55022/EN55024/EN61000-3-2,3/EN61000-4-2,3,4,5,6,8,115
Net Weight
0.85 Kg
Cooling
Natural cooling
