PV Installation manual
PanelVisa
A-3
Industrial Touch Panel
PV035 Specifications
Items
PV035-TST PV035-TNT
Display Type
Color mode TFT LCD,
256 colors
Color mode TFT LCD,
256 colors
Display Size
3.5" (diagonal)
Number of Pixels
320X240
Display Adjustment
X
Back Light
LED; Life time is 100,000 hours
Touch Screen
Yes Yes
Switch Key
X X
Input Power
24VDC±10%; Isolation; Under 5W
CPU
RISC ARM 32Bit CPU
Flash Memory
4M Bytes 4M Bytes
System working Memory
1M Bytes 2M Bytes
Battery Backed Memory
128K Bytes(Standard) ~1M Bytes
Communication Ports
COM1/9pin Female: RS232/RS422/RS485;
COM2; 4pin Plug Connector RS422/RS485
Ethernet Port
X Yes
Extension Bus Port
X X
Front Panel Seal
IP65 / NEMA 4
Operating Temperature
0~50°C
Storage Temperature
-20~60°C
Ambient Humidity
20-90% RH (non-condensing)
Vibration Endurance
0.5mm displacement, 10-55Hz, 30Min. per X, Y, and Z-axis directions
Shock Endurance
10G, 11ms three times in each direction of X, Y, and Z axes
RFI testing
FCC Part15 Class A
Radiated Disturbance Test
EN 55022/1998+A1:2000
Electrostatic Discharge Test
EN61000-4-2/1995+A1:1998
RF Electromagnetic Field Test
EN61000-4-3/1996+A1:1998
Surge Immunity Test
EN61000-4-5/1995
EMC Test Report
EN55022/EN55024/EN61000-3-2,3/EN61000-4-2,3,4,5,6,8,115
Net Weight
0.3Kg 0.3Kg
Cooling
Natural cooling
