Using the CVE-10/12/15 as a floor/stage monitor
The CVE-10, CVE-12, and CVE-15 can be used as floor monitors by orienting them as shown below. This places them at a
fixed 45-degree angle toward the performers. It is recommended to use MONITOR mode for this application, as it reduces
the volume of frequencies that are prone to feedback. Be sure that the loudspeaker and cables are not located where
they can become a tripping hazard. It is recommended to use right-angle XLR or right-angle ¼” jacks where possible to
avoid cable binding between the loudspeaker and the stage.
STAGE

Cerwin-Vega CVE-12 Specifications

General

Amplifier class	D
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Bluetooth	Yes
Connectivity technology	Wired & Wireless
Frequency range	44 - 23000 Hz
RMS rated power	1000 W
Sound pressure level (max)	126 dB
Product color	Black
Housing material	Polymer
Recommended usage	Universal
Quantity per pack	1 pc(s)
XLR/TRS in combo port	1
Speaker type	2-way
Number of drivers	-
Speaker placement	Floor
Audio output channels	- channels

Weight and Dimensions

Depth	318 mm
Width	356 mm
Height	616 mm
Weight	14960 g
