CERWIN-VEGA PROFESSIONAL
9
Rear Panel – Mixer – CVE-18s
DSP MODE SELECT
This button allows one of two EQ presets to be chosen:
LIVE PA This mode is best used for live music sound. It
has a deeper, more-balanced low-end response.
CLUB/DJ This mode adds definition and punch to sub
frequencies. It is primarily used for playback of music
styles such as EDM, pop, and hip hop.
OUTPUT SELECT
This button allows one of two frequency outputs to be
chosen:
100Hz HPF This is a high-pass filter that provides a
crossover to top boxes.
FULL RANGE – This leaves the output jacks at full range.
BLUETOOTH
The CVE series has True Wireless Stereo (TWS) Bluetooth connectivity. To pair a CVE speaker with a streaming
device, push the PAIR/LINK button once. When the PAIR/LINK button begins flashing blue, the speaker will beep
twice and appear in the available Bluetooth devices list on the streaming device. After the speaker is selected and
successfully paired, it will beep once, and the PAIR/LINK button will be lit blue.
To link two CVE speakers together, push and hold the PAIR/LINK button on the first speaker (that has already
been paired with the streaming device). When its PAIR/LINK button begins flashing orange, the first speaker will
beep twice. Then, push and hold the PAIR/LINK button on the second speaker. The PAIR/LINK buttons on both
speakers will blink orange for approximately five seconds before turning solid orange; this indicates that both
speakers are successfully paired and linked to your streaming device. Once linked, the speakers can be toggled
between mono and stereo by double-tapping the PAIR/LINK button on either speaker while audio is playing.
Note: The Bluetooth level knob adjusts the level of the Bluetooth audio input. Beeps will be heard only if the
Bluetooth level is turned up. CVE speakers cannot be paired, unpaired, or linked while audio is playing.
CH1 INPUT and CH2 INPUT
These are balanced combo inputs for balanced XLR/TRS cables. They accept line-level input only.
LEVEL
The LEVEL knob adjusts the output level of the speaker for all channels equally.
CH1 OUTPUT and CH2 OUTPUT
CH1 OUTPUT and CH2 OUTPUT combine the incoming Bluetooth signal with CH1 INPUT and CH2 INPUT,
respectively, for connecting to another powered speaker or a recording device. These outputs are not affected
by changes to the LEVEL knob.
