Cerwin-Vega CVE-12 User Manual

CERWIN-VEGA PROFESSIONAL
12
Application #1 – Using a single CVE-10, CVE-12, or CVE-15
A single CVE-10, CVE-12, or CVE-15 powered speaker can be used to reinforce sound for a wide variety of performances.
The diagram below shows an application where a vocal microphone, a line mixer, and a Bluetooth™ streaming device are
all being used simultaneously. Each channel level can be adjusted to balance channel volumes, while the Bluetooth™ level
knob independently adjusts the Bluetooth™ signal volume.
Input
Equipment
Cable Type
CH 1 INPUT Mixing Console or Microphone Balanced XLR or ¼” TRS
CH 2 INPUT Mixing Console or Microphone Balanced XLR or ¼” TRS
(Bluetooth™) Media Player Bluetooth™ Streaming Device Bluetooth™ Wireless
or
or

Cerwin-Vega CVE-12 Specifications

General

Amplifier class	D
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Bluetooth	Yes
Connectivity technology	Wired & Wireless
Frequency range	44 - 23000 Hz
RMS rated power	1000 W
Sound pressure level (max)	126 dB
Product color	Black
Housing material	Polymer
Recommended usage	Universal
Quantity per pack	1 pc(s)
XLR/TRS in combo port	1
Speaker type	2-way
Number of drivers	-
Speaker placement	Floor
Audio output channels	- channels

Weight and Dimensions

Depth	318 mm
Width	356 mm
Height	616 mm
Weight	14960 g
