CERWIN-VEGA PROFESSIONAL

Application #2 – Connecting a second CVE-10, CVE-12, or CVE-15 using MIXED

OUTPUT

A second CVE-10, CVE-12, or CVE-15 loudspeaker can be added using a standard balanced XLR cable as shown in the

example below. A two-speaker system can cover a wider audience and situations where more volume is needed. To add

a second CVE-10, CVE-12, or CVE-15 loudspeaker, connect the MIXED OUTPUT of the first speaker to CH 1 INPUT or CH 2

INPUT of the second speaker. Then, adjust the LEVEL to an appropriate setting on the first speaker. Be sure to adjust the

LEVEL knobs on both speakers to similar settings since the LEVEL knob on the first speaker will not change the volume on

the second speaker.
