3-313-31
9 - P CUTBACK SPEED1
10 - P ACC DELAY
11 - P DEC DELAY
DESCRIPTION MIN. MAX STEP UNIT
This parameter determines the pump motor speed reduction in relation
to the state of the microswitch (normally closed N.C.) between pin 13
connector JP and pin 9 connector JP:
0 100 10 %
Microswitch open = reduction on
Microswitch closed = reduction off
Minimum setting = maximum reduction
Maximum setting = no reduction
DESCRIPTION MIN. MAX STEP UNIT
Determines the acceleration ramp of the pump motor 1.0 4.6 0.4 Sec
Minimum setting = maximum acceleration
Maximum setting = minimum acceleration
DESCRIPTION MIN. MAX STEP UNIT
Determines the deceleration ramp of the pump motor 1.0 4.6 0.4 Sec
Minimum setting = maximum acceleration
Maximum setting = minimum deceleration
