4D UNUSED UNUSED 4-43
4E CONTACTOR CLOSED LIFTING LOGIC UNIT: Failure on the contactor driver 4-44
5A CHOPPER NOT CONF UNUSED 4-44
5B STEER WIRE KO LIFTING LOGIC UNIT: Failure on the contactor driver 4-44
5C DATA ACQUISITION LIFTING LOGIC UNIT: Logic in data acquisition phase 4-44
5D WRONG 0 VOLT LIFTING LOGIC UNIT: Control internal error 4-45
5E HANDBRAKE LIFTING LOGIC UNIT: Brake microswitch failure 4-45
5F
WRONG RAM
MEMORY
LIFTING LOGIC UNIT: Protection activated
against electrostatic charges
4-45
8A PARAM LOAD ERROR I/O CARD: Problem in the hardware circuits 4-64
8B TRUCK IN ALARM I/O CARD: General alarm 4-65
8C
TRUCK STUFFING
ERROR
I/O CARD: Comunication problem 4-65
8D UNUSED UNUSED 4-65
8E UNUSED UNUSED 4-65
8F FW + BW I/O CARD: Double request activated. 4-65
A1 EEPROM KO MHYRIO LOGIC UNIT: Defect in the memory area 4-46
A2 EV DRIVER SHORT
MHYRIO LOGIC UNIT: One of the on/off valves driver is shorted
circuit
4-46
A3 CAN BUS KO MHYRIO LOGIC UNIT: Can bus communication error 4-46
A4 FF VALVES MHYRIO LOGIC UNIT: Problem is in the hardware circuit 4-47
A5 UNUSED UNUSED 4-47
A6 EVPG1 DRIV SHORT
MHYRIO LOGIC UNIT: One of the valve controls is in short
circuit
4-47
A7 EVPG2 DRIV SHORT
MHYRIO LOGIC UNIT: One of the valve controls is in short
circuit
4-48
A8 EVPG3 DRIV SHORT
MHYRIO LOGIC UNIT: One of the valve controls is in short
circuit
4-48
A9 EVPG4 DRIV SHORT
MHYRIO LOGIC UNIT: One of the valve controls is in short
circuit
4-48
AA
WRONG SET
BATTERY
MHYRIO LOGIC UNIT: Battery voltage out of range 4-49
AB HI SIDEDRIVER KO MHYRIO LOGIC UNIT: Problem is in the hardware circuit 4-49
AC EVPG1 DRIVER KO MHYRIO LOGIC UNIT: One of the valve controls is open 4-49
AD EVPG2 DRIVER KO MHYRIO LOGIC UNIT: One of the valve controls is open 4-50
AE EVPG3 DRIVER KO MHYRIO LOGIC UNIT: One of the valve controls is open 4-50
AF EVPG4 DRIVER KO MHYRIO LOGIC UNIT: One of the valve controls is open 4-50
B0 COIL SHORTED MHYRIO LOGIC UNIT: Problem is in the hardware circuit 4-51
B1 UNDER VOLTAGE MHYRIO LOGIC UNIT: Undervoltage condition 4-51
B2 EVP DRIVER KO MHYRIO LOGIC UNIT: The valve control is open 4-51
B3 EV DRIVER KO MHYRIO LOGIC UNIT: One of the valve controls is open 4-52
When an Error Code is Displayed
Code Alarm specification Error mode Page
