MAST
REMOVAL • INSTALLATION
T=N·m
Removal procedure
1. Put the mast in vertical position
2. Disconnect the battery connector
3. Connect the chains on the mast [Point 1]
4. Disconnect the hydraulic hoses from the mast (lifting, sideshift, ...)
5. Remove the bolts of the mast [Point 2]
6. Remove the pins from the tilting cylinders [Point 3]
7. Remove the mast
Installation procedure
The reassembly procedure is the reverse of the disassembly procedure.
Note:
Apply appropriate grease to the mast support bushing, mast support cap interior surfaces and
tilting cylinder front pins
M = 83 Nm (± 15%)
M = 24 Nm
(± 10%)
