Cessna 150J - Page 103

d. (Refer to figure 6-3.) Adjust turnbuckles at
bellcranks (11) so stop bushings (17) are centered
in bellcrank slots with 40 ± 10 pounds tension on
carry-thru cable (16). Disregard tension on direct
cables, which will be different than tension on carry-
thru cable.
e. Adjust push-pull rod (7) at each aileron until
ailerons are neutral with reference to the trailing
edge of wing flaps. Be sure wing flaps are fully
up when making this adjustment. Tighten push-pull
rod jam nuts.
SHOP NOTES:
f. Safety all turnbuckles by the single-wrap method
using O. 040-inch monel safety wire.
g. Remove bar from control wheels and install all
parts removed for access.
h. Check ailerons for correct travel, using in-
clinometer shown in figure 6-4.
IWARNING'
Be sure ailerons move in correct direction
when operated by control wheel.
6-7/(6-8 blank)
