INSTRUMENT PANEL
1 2 4 5 6 7 8 10
3 9 11
12 13 14 15 17 19 21 23 25 27 28
16 18 20 22 24 26
1. Oil Temperature/Oil Pressure
2. Fuel Quantity Indicators
3. Suction gage
4. Clock/Timer
5. Air Spee Indicator
6. Attitude Indicator
7. Altimeter
8. Course Deviation Indicator
9. Magnetic Compass
10. COM/NAV Radios
11. Autopilot
12. Ammeter
13. Master Switch
14. Primer
15. Ignition Switch
16. Thermometer
17. Tachometer
18. Turn Coordinator
19. RGT / CHT
20. Heading Indicator
21. Circuit Breakers/Light
Switches
22. Vertical Speed Indicator
23. Instrument Lighting Dimmer
24. Carburetor Heat
25. Throttle Control
26. Course Deviation Indicator
27. Mixture Control
28. Wing Flap Switch
FLIGHT SIMULATION USE ONLY
AIRPLANE & SYSTEMS DESCRIPTION
PAGE 1
