DESCRIPTIVE DATA
ENGINE
- Number of engines: 1
- Engine Manufacturer: Avco
Lycoming
- Engine Model Number: O-320-
D2J
- Engine Type: Normally
aspirated, direct-drive, air-cooled,
horizontally opposed, carburetor
equipped, four-cylinder engine
with 319.8 cu.in. displacement
- Horsepower Rating and Engine
Speed: 160 rated HP at 2700 RPM
PROPELLER
- Propeller Manufacturer:
McCauley Accessory Division.
- Propeller Model Number:
1C160/DTM7557
- Number of Blades: 2
- Propeller Diameter, Maximum:
75 inches, Minimum: 74 inches.
- Propeller Type: Fixed Pitch
FUEL
Approved Fuel Grades:
100LL Grade Aviation Fuel (Blue)
100 (Formerly 100/130) Grade Aviation Fuel (Green)
Fuel Capacity:
Standard Tanks:
Total Capacity: 43 gallons
Total Capacity Each Tank: 21.5 gallons
Tatoal Usable: 40 gallons.
Long Range Tanks:
Total Capacity: 54 gallons
Total Capacity Each Tank: 27 gallons
Tatoal Usable: 50 gallons.
Integral Tanks:
Total Capacity: 68 gallons
Total Capacity Each Tank: 34 gallons
Tatoal Usable: 62 gallons.
NOTE:
Isopropyl alcohol or ethylene
glycol monomethyl ether may be
added to the fuel supply.
NOTE:
To ensure maximum fuel capacity
when refueling and minimize
cross-feeding when parked on a
sloping durface, place the fuel
selector valve in either LEFT or
RIGHT position.
OIL
Oil Grade (Specififications):
MIL-L-6082 Aviation Grade
Straight Mineral Oil: Use to
replenish supply during first 25
hours and at the forst 25-hour
oil change. Continue to use until
a total of 50 hours has
accumulated or oil consumption
has stabilized. MIL-L-22851
Ashless Dispersant Oil: This oil
must be used after first 50 hours
or oil consumption has stabilized.
FLIGHT SIMULATION USE ONLY
GENERAL INFORMATION
PAGE 3
