CF MOTO 300CL-X - General Torque Sheet; Vehicle Key Parts Torque Sheet

119
General Torque Sheet
Type Torque N•m Type Torque N•m
M5 bolt, nut
M6 bolt, nut
M8 bolt, nut
M10 bolt, nut
M12 bolt, nut
5±1
10±1
20~30
30~40
40~50
M5 screw
M6 screw
M6 anged bolt, nut
M8 anged bolt, nut
M10 anged bolt, nut
4±1
9±1
12±1
20~30
30~40
Vehicle Key Parts Torque Sheet
Type Thread Piece Tightening Torque N•m
Engine rear lower mounting nut GB/T6187 M8 1 25~30
Engine front upper mounting bolt GB/T5789 M10×90 1 45~50
Engine front lower mounting nut GB/T5789 M10×140 1 45~50
Frame front lower mounting nut GB/T5789 M10×170 1 45~50
Side stand bolt A000-030006 1 15~20
Side stand bolt and nut GB/T6187 M10×1�25 1 5~10
Front wheel axle 6KJ0-070001 M12×1�25×192 1 50~80
Rear fork tightening nut GB/T6187 M15×1�5 1 80~100
Rear wheel axle tightening nut GB/T6187 M14×1�5 1 80~100
Steering column tightening nut A000-050007 M35×1 1 20
Upper triple clamp locking screw A000-050003 M26×1 1 110
Upper and lower triple clamp
absorber locking screw
GB/T 70�1 M8×25 6 20~25
