Clutch Lever Freeplay
Check clutch lever smoothness�
Turn handlebar towards the left to the end�
Slowly pull the clutch lever until the resistance is evident� Check clutch lever position where the clearance
is for freeplay
。
Free play
：
0.39 in. ~ 0.78 in. (10 mm ~ 20 mm)
WARNING
If there is no free play for clutch lever, the clutch will start to slip�
Check lever free play every time before starting the engine�
Set the clutch lever freeplay when necessary�
Clutch lever free play ne adjustment
Turn handlebar towards the left to the end�
Loosen lock nut
1
and rotate the adjusting nut
2
for
adjustment�
Once the desired freeplay is achieved, tighten the lock
nut
1
�
2
1
0�39 in� ~ 0�78 in�
