94
Brake System
In order to guarantee excellent performance of your vehicle and personal safety, please repair and
maintain the vehicle according to the Periodic Maintenance Chart� Make sure all the parts of the brake
system are in good state� If any damage occurs to the brake system, have your vehicle inspected by
authorized dealer�
Front Brake Lever Inspection
Park with the side stand on level ground�
Grip lightly the front brake lever and inspect its free travel�
Free travel: 0.12 in. ~ 0.24 in. (3 mm ~ 6 mm)
Inspect the front brake lever for any cracks or abnormal noise�
Replace with new parts if problems are discovered�
Rear Brake Pedal Inspection
Park with the side stand on level ground�
Lightly apply the rear brake pedal and inspect its free travel�
Free travel: 0.39 in. (10 mm)
Inspect the rear brake pedal for any cracks or abnormal noise�
Replace with new parts if problems are discovered�
WARNING
If the brakes feel soft when applying the brake lever or brake pedal, there may be air in a brake uid
hose or lack of uid. If the vehicle has this dangerous condition, do not drive the vehicle. Have the brake
system checked immediately by an authorized CFMOTO dealer�
0�12 in� ~ 0�24 in�
0�39 in�
